HPE6-A72 Online Practice Questions and Answers

HOTSPOT

Review the exhibit.

As the frame traverses from **PC-1** to **Server-1**, the VLAN tag will be removed.

Click on the interface (circled in green) where the VLAN tag will be removed.

Hot Area:

DRAG DROP

Match each network protocol to the correct default listening port and transport protocol. Not all answers will be used.

Select and Place:

Core# configure terminal Core(config)# vrf Green Core(config-vrf)# exit Core(config)# Core(config)# interface vlan 50 Core(config-if-vlan)# ?

Given the configuration on the CORE switch shown above, what command would follow to assign the switched virtual interface (SVI) vlan 50 to the VRF created?

A. Core(config-if-vlan)# vrf attach Green

B. Core(config-if-vlan)# ip vpn-instance Green

C. Core(config-if-vlan)# ip vrf forwarding Green

D. Core(config-if-vlan)# routing-context Green vrf

The section in blue can be ignored.

SW1(config)# interface 1/1/1-1/1/2 SW1(config-if-<1/1/1-1/1/2)# vlan access 2 SW1(config-if-<1/1/1-1/1/2)# exit SW1(config)# interface 1/1/11-1/1/17 SW1(config-if-<1/1/11-1/1/17)# vlan access 17 SW1(config-if-<1/1/11-1/1/17)# exit

After completing the above commands, what is the expected output of show vlan with no other vlan commanded having been added?

A. Option A

B. Option B

C. Option C

D. Option D

What connectivity commands are available on AOS-CX switches? (Choose two.)

A. netstatus

B. traceroute

C. ping

D. pathping

E. tracert

Which two statements are true regarding Checkpoints on Aruba switches? (Choose two.)

A. Rolling back to a prior checkpoint triggers a reboot of the switch.

B. Stacking switches using VSF or VSX will disable the Checkpoint feature.

C. A checkpoint is a snapshot of the running-configuration and relevant metadata at the time the checkpoint was created.

D. System-generated checkpoints are created after a configuration change and 5 minutes of inactivity.

E. Checkpoints are available on AOS 5400R switches, as well as on all AOS-CX switches.

Refer to the exhibit.

The above command was applied to an Aruba AOS-CX 6300M 24-port switch with 4-port SFP56 uplinks. All ports are set as access switchports.

Which ports carry VLAN 1 traffic?

A. 1/1/8, 1/1/10, 1/1/5-1/1/24

B. 1/1/1-1/1/28

C. 1/1/1-1/1/24

D. 1/1/8-1/1/10, 1/1/5-1/1/28

Aruba Access Points tunnel traffic in a campus to the Mobility Controller using which protocol?

A. Control and Provisioning of Wireless Access Points (CAPWAP)

B. Generic Routing Encapsulation (GRE)

C. Lightweight Access Point Protocol (LWAPP)

D. Process Application Programming Interface (PAPI)

Which option correctly describes a WAN network?

A. a group of computer resources that communicates between geographically separate location

B. the connection between two separate buildings in the same campus

C. a network of devices over long distances but limited to within a single ISP

D. compute resources that are networked locally over wireless

Refer to the exhibit.

What VSF command produces the above output?

A. show vsf member

B. show vsf link

C. show vsf topology

D. show vsf detail
